Type                               옥내 고정 설치용                                     /  옥내 고정 설치용
드랙 체인용                    1×2×0.64㎜ (stranded)                                        /  1×2×0.64㎜ (stranded)

내부도체지름                               나동선(AWG22/7)                                                     /   나동선(AWG22/7)
코아절연                                        Foam-skin-PE                                                          /   Foam-skin-PE
코아색상                                        백/갈                                                                               /   백/갈, 황/녹
피복요소                                        더블 코어+서로꼬아진 2필러스                                  /  Star quad

쉴드 1                                             -                                                                                      /   -

쉴드 2                                             -                                                                                      /   -
토탈쉴드                                         주석도금 구리 편조                                                       /   주석도금 구리 편조
외피 재료                                        PUR                                                                                /   PUR
케이블외부지름                             6.9㎜ ± 0.3㎜                                                              /   7.5㎜ ± 0.3㎜
외피색상                                         RAL 4001와 유사한 보라색                                        /   RAL 4001와 유사한 보라색

Electrical data

임피던스특징                                   120 Ohm ± 10%                                                       /   120 Ohm ± 10%
도체저항                                           56.0 Ohm/㎞ max.                                                    /   56.0 Ohm/㎞ max.
절연저항                                           5.00 GOhm × ㎞ min.                                              /   5.00 GOhm × ㎞ min.
상호정전용량                                   40.0 ㎋/㎞ nom.                                                          /   40.0 ㎋/㎞ nom.

정격전압                                           250 V                                                                              /   250 V​
테스트전압                                       1.5 ㎸                                                                              /   1.5 ㎸

Technical data

무게                                                      약 47.0 ㎏/㎞                                                              /   약 64.0 ㎏/㎞
최하 부설반경 범위                            70.0 ㎜                                                                         / 750.0 ㎜
최소온도범위                                      -30 ℃                                                                          /   -30 ℃
최대온도범위                                      +70 ℃                                                                          /  +70 ℃
Caloric load, approx. value        1.20 MJ/m                                                                 /  1.20 MJ/m
구리무게                                              30.0 ㎏/㎞                                                                   /   42.0 ㎏/㎞

Norms

적용가능한 기준                                Profius acc. to DIN 19245 T3 and EN50170  /   Profius acc. to DIN 19245 T3 and EN50170

UL-style                                           CMX 444                                                                      /   CMX 444

용도

CAN bus 시리즈(제어 지역 네트워크)는 다양한 필드 버스 시스템임. 자동화 기술, 콤플렉스 컨트롤러와 제어 기기등에 연결함.

직물이나 공사 기계, 의학 기술 산업등에 본 시스템을 사용함. 이 케이블은 옥내 고정설치에 적합함. 경제적인 버스 시스템 솔루션. 이 케이블은 고 후랙시블용으로 제작됨
